| ब्रांड नाम: | HongCe |
| मॉडल संख्या: | एक्सजेजे |
| एमओक्यू: | 1 सेट |
| कीमत: | Negotiatable |
| भुगतान की शर्तें: | टी/टी |
| आपूर्ति करने की क्षमता: | प्रति माह 15 सेट |
| Item | XJJ-5 | XJJY-5 | XJJ-50 | XJJY-50 |
|---|---|---|---|---|
| The release way of controlling | electronic control | electronic control | electronic control | electronic control |
| The numerical value displayed | Pointer | Digital display | Pointer | Digital display |
| The energy of the pendulum bob (J) | 1, 2,4, 5 | 1, 2,4,5 | 7.5,15,25, 50 | 7.5, 15, 25,50 |
| The moment of the pendulum bob (N.M) | 1J PL=0.516, 2J PL=1.031, 4J PL=2.062, 5J PL=2.578 |
1J PL=0.516, 2J PL=1.031, 4J PL=2.062, 5J PL=2.578 |
7.5J PL=3.866, 15J PL=7.733, 25J PL=12.889, 50J PL=25.777 |
7.5J PL=3.866, 15J PL=7.733, 25J PL=12.889, 50J PL=25.777 |
| Min scale mark | 1/100 | 1/100 | 1/100 | 1/100 |
| Impact speed m/s | 2.9 | 2.9 | 3.8 | 3.8 |
| The pre-elevation of the pendulum bob | 160° | 160° | 160° | 160° |
| The distance from the pendulum shaft center to the sample center (mm) | 221 | 221 | 380 | 380 |
| The fillet radius of the jaw (mm) | 1 | 1 | 1 | 1 |
| The angle of the impact blade | 30° | 30° | 30° | 30° |
| The fillet radius of the impact blade | 2mm | 2mm | 2mm | 2mm |
| The weight of the machine base | It is more than 40 times of the heaviest pendulum bob and it can be adjusted to the horizontal station | |||
| Power supply | 220V/50HZ | |||
| Sample Type | Length C | Width B | Thickness D | Offset Distance |
|---|---|---|---|---|
| Ⅰ | 80 | 10 | 4 | 60/62 |
| Ⅱ | 50 | 6 | 4 | 40 |
| Ⅲ | 120 | 15 | 10 | 70 |
| Ⅳ | 125 | 13 | 13 | 95 |
